Mn13 High Manganese Carbon Steel Plate Sheet Hot Rolled Wear Resistant Plate

Mn13 High Manganese Steel Wear Plate - Impact resistance experts, the more you wear, the harder it gets (in line with GB/T 5680 standard)

Product Overview

Mn13 high manganese steel (also known as Hadfield steel) is a classic wear-resistant material that follows the GB/T 5680-2010 standard. Its most remarkable feature is that when subjected to strong impact or extrusion, the surface will harden rapidly (work-hardening effect), and the hardness can be greatly increased to more than HBW 500, while the heart still maintains excellent toughness. It is an irreplaceable special steel for high impact and high stress wear conditions.

Core properties and advantages

   Unique work-hardening properties: "The more impact, the harder", especially suitable for wear conditions with severe impact.

   Unrivalled toughness: one of the highest of all wear-resistant materials, never brittle fracture.

   Non-magnetic: suitable for special environments where non-magnetic properties are required.

   King of impact wear resistance: under impact loads, its wear resistance far exceeds that of other steels with the same static hardness.

Typical application areas

   Jaw crusher plates, cone mill walls, crushing walls in mining and metallurgical industries.

   Railway turnouts, tank track plates.

   Excavator bucket tooth tip, bucket liner under strong impact conditions.

   Ball mill liner.

Technical parameters (in line with GB/T 5680-2010 standard)

| Item | Parameter index | Remarks |

| Brinell hardness, HBW (initial) | ≤ 225 | After use due to work hardening can be significantly increased |

| Tensile strength Rm, MPa | ≥ 800 | - | | Elongation after break A

| Elongation at break A, % | ≥ 35 | for very high toughness

| Impact function AKU2, J | ≥ 118 | - | Chemical composition (melting)

| Chemical composition (melt analysis), % |

| Chemical composition (melt analysis), % | Carbon (C) | 1.00 - 1.40 | High carbon content ensures hardenability | Manganese (Mn) | | Manganese (Mn)

Manganese (Mn) | 11.00 - 14.00 | Core element for ultra-high toughness and austenitic organisation | Silicon (Si) | 1.00 - 1.40

| Silicon (Si) ≤ 0.30 - 0.80 | - |

| Phosphorus (P) ≤ | 0.060 | - |

| Sulphur (S) ≤ | 0.040 | - |

(Note: The above are typical values, the specific parameters are subject to the material certificate provided by our company).

Our Service and Commitment

   Various specifications: We can provide different thickness, width and length of steel plates according to customers' requirements.3-150mm

   Customised cutting: We provide accurate flame cutting, plasma cutting or laser cutting services to reduce your processing steps.

   Professional technical support: Our technical team can provide you with professional advice on material selection, processing and welding.

Contact us today for a customised product solution and quotation!
