NM600 Wear Resistant Steel Plate Hot Rolled

NM600 Top Strength Wear Resistant Steel Plate - The pinnacle of wear resistance, designed for the rigours of the job (GB/T 24186 compliant)

Product Overview

NM600 is the top strength grade wear-resistant steel in GB/T 24186-2009 standard, which has the highest hardness and wear-resistant grade in the current industrial field. It is designed for the "devil" working conditions of extreme wear and impact, and is the ultimate weapon to extend the life of critical equipment and maximise production efficiency.

Core features and benefits

   Peak Wear Hardness: Hardnesses up to HBW 570-630 provide unrivalled resistance to wear and tear.

   Extreme mechanical strength: Highest tensile and yield strengths for extreme heavy-duty conditions.

   Technological leadership: represents the highest level of heat treatment and demands on the production process.

   Solving core wear problems: Used in the most abrasive parts of the machine, it extends its life many times over.

Typical application areas

   Reinforcement of the bottom and side plates of mining dump trucks.

   Blades and liners of shot blasting machines.

   Key wear parts of coal mills.

   Sand and gravel processing equipment under the most severe working conditions.

Technical parameters (in line with GB/T 24186-2009 standard)

| Item | Parameter Index |

| Brinell hardness, HBW | 570 - 630 |

| | Tensile strength Rm, MPa | ≥ 1650 |

| Yield strength Rp0.2, MPa | ≥ 1400 | Elongation at break A, MPa ≥ 1400

| Yield strength Rp0.2, MPa ≥ 1400 | Elongation at break A, % ≥ 6 | Chemical composition (melting)

| Chemical composition (melt analysis), % | ≥ 6

Carbon (C) ≤ | 0.30 | | Silicon (Si) ≤ | 0.30

| Silicon (Si) ≤ | 0.70 | Manganese (Mn)

| Manganese (Mn) ≤ 1.60

Phosphorus (P) ≤ | 0.020 | Sulphur (S) ≤ | 0.020

Sulphur (S) ≤ | 0.010 | Other Alloying Elements | Moderate

| Other Alloying Elements | Add in Moderate Amounts | | Sulphur ≤ | 0.010

(Note: The above are typical values, the specific parameters are subject to the material certificate provided by our company).

Our Service and Commitment

   Various specifications: We can provide different thickness, width and length of steel plates according to customers' requirements.3-150mm

   Customised cutting: We provide accurate flame cutting, plasma cutting or laser cutting services to reduce your processing steps.

   Professional technical support: Our technical team can provide you with professional advice on material selection, processing and welding.

Contact us today for a customised product solution and quotation!
