NM500 Wear Resistant Steel Plate Hot Rolled

NM500 Ultra High Strength Wear Resistant Steel Plate - Benchmark Performance, Widely Used (Conforms to GB/T 24186 Standard)

Product Overview

NM500 is one of the most widely used ultra-high strength wear-resistant steel plates in the market, which strictly complies with GB/T 24186-2009 standard. With extremely high hardness and excellent wear resistance, it is the material of choice to cope with strong abrasion and high stress working conditions, achieving the best balance between durability and comprehensive cost.

Core properties and benefits

   Excellent wear resistance: Hardnesses up to HBW 470-530 can withstand extremely strong abrasive wear.

   Very high strength: Very high tensile and yield strengths for use in critical load-bearing structural components.

   Excellent overall performance: Weldability and formability at high hardness are ensured by advanced alloy design and heat treatment processes.

   Wide range of applications: From construction machinery to mining equipment, NM500 is a localised model to replace imported high-end wear-resistant steels.

Typical application areas

   Key wear-resistant parts of large excavators and loaders.

   Bottom and side plates of dump trucks, crusher liners.

   Jaw crusher tooth plate, trommel screen liner.

   Bins and chutes in strong abrasive environment.

Technical parameters (in line with GB/T 24186-2009 standard)

| Item | Parameter Index |

| Brinell hardness, HBW | 470 - 530 |

| | Tensile strength Rm, MPa | ≥ 1450 |

| Yield strength Rp0.2, MPa | ≥ 1200 | Elongation at break A, MPa ≥ 1200

Yield strength Rp0.2, MPa | ≥ 1200 | Elongation at break A, % | ≥ 8 | Chemical composition (melting)

| Chemical composition (melting analysis), % |

Carbon (C) ≤ | 0.30 | | Silicon (Si) ≤ | 0.30

Silicon (Si) ≤ | 0.70 | | Manganese (Mn)

| Manganese (Mn) ≤ 1.60

Phosphorus (P) ≤ | 0.020 | Sulphur (S) ≤ | 0.020

Sulphur (S) ≤ | 0.010 | Other Alloying Elements | Moderate

| Other Alloying Elements | Add in Moderate Amounts | | Sulphur ≤ | 0.010

(Note: The above are typical values, the specific parameters are subject to the material certificate provided by our company).

Our Service and Commitment

   Various specifications: We can provide different thickness, width and length of steel plates according to customers' requirements.3-150mm

   Customised cutting: We provide accurate flame cutting, plasma cutting or laser cutting services to reduce your processing steps.

   Professional technical support: Our technical team can provide you with professional advice on material selection, processing and welding.

Contact us today for a customised product solution and quotation!
