NM450 Wear Resistant Steel Plate Hot Rolled

NM450 High Strength Wear-resistant Steel Plate - Balanced wear resistance, economic and practical (in accordance with GB/T 24186 standard)

Product Overview

NM450 is a high-strength wear-resistant steel plate following the GB/T 24186-2009 standard, whose wear resistance and strength are steadily improved on the basis of NM400. This product has an excellent balance between hardness, toughness and workability, and is suitable for wear environments with moderate impact conditions, making it a cost-effective wear-resistant solution.

Core properties and benefits

   Excellent wear resistance: Hardness up to HBW 420-480, significantly better than NM400.

   Good toughness match: Increased hardness while retaining sufficient toughness to cope with impacts.

   Moderately difficult to machine: NM450 is easier to cut, bend and weld than higher grade wear-resistant steels.

   Cost-effective: NM450 is the most cost-effective choice for applications requiring more wear resistance than NM400, but with a slight performance premium over NM500.

Typical Applications

   Bucket liners for medium excavators and loaders.

   Carriage and hopper liners in mining equipment.

   Wear-resistant parts of agricultural machinery.

   Material conveying system under medium and low impact working conditions.

Technical parameters (in line with GB/T 24186-2009 standard)

| Item | Parameter Index |

| Brinell hardness, HBW | 420 - 480 |

| Tensile Strength Rm, MPa | ≥ 1350 |

| Yield strength Rp0.2, MPa | ≥ 1100 | Elongation at break A, MPa ≥ 1100

Yield strength Rp0.2, MPa ≥ 1100 | | Elongation at break A, % ≥ 10 | | Chemical composition (melting)

| Chemical composition (melt analysis), % | ≥ 10

Carbon (C) ≤ | 0.25 | Silicon (Si) ≤ | 0.25

| Silicon (Si) ≤ | 0.70 | Manganese (Mn)

| Manganese (Mn) ≤ 1.60

Phosphorus (P) ≤ | 0.020 | Sulphur (S) ≤ | 0.020

Sulphur (S) ≤ | 0.010 | Other Alloying Elements | Moderate

| Other Alloying Elements | Add in Moderate Amounts | | Sulphur ≤ | 0.010

(Note: The above are typical values, the specific parameters are subject to the material certificate provided by our company).

Our Service and Commitment

   Various specifications: We can provide different thickness, width and length of steel plates according to customers' requirements.3-150mm

   Customised cutting: We provide accurate flame cutting, plasma cutting or laser cutting services to reduce your processing steps.

   Professional technical support: Our technical team can provide you with professional advice on material selection, processing and welding.

Contact us today for a customised product solution and quotation!
