NM550 Extra High Strength Wear Resistant Steel Plate - Toughness and Wear Resistance, Responding to the Limit (Conforms to GB/T 24186 Standard)
Product Overview
NM550 is an extra-high strength grade wear-resistant steel in GB/T 24186-2009 standard, which represents the advanced level of domestic wear-resistant steel. It further enhances the hardness and strength on the basis of NM500, and is designed for extreme working conditions subject to the harshest abrasion and moderate impact.
Core properties and advantages
Extreme wear resistance: Hardness of HBW 520-580 for the most demanding abrasive wear environments.
Extremely high load carrying capacity: Very high yield strength for thin-walled, lightweight and heavy equipment components.
Excellent toughness reserve: Despite the extreme hardness, the necessary impact toughness is maintained by technical means.
Lightweight design possibilities: Thinner NM550 can meet or exceed the performance of thicker grades of lower grades of steel, enabling equipment weight reduction.
Typical application areas
Large mining dump truck carriages.
Power crusher hammers and liners.
Neutral mill rolls and disc linings in the cement industry.
Edge plate of large hopper and pile reclaimer in iron and steel mills.
Technical parameters (in line with GB/T 24186-2009 standard)
| Item | Parameter index |
| Brinell Hardness, HBW | 520 - 580 | Tensile Strength Rm, HBW
| Brinell hardness, HBW | 520 - 580 | Tensile strength, Rm, MPa | ≥ 1550 |
| Yield strength Rp0.2, MPa | ≥ 1300 | Elongation at break A, MPa ≥ 1300
| Yield strength Rp0.2, MPa ≥ 1300 | Elongation at break A, % ≥ 7 | Chemical composition (melt)
| Chemical composition (melting analysis), % | ≥ 7
Carbon (C) ≤ | 0.30 | Silicon (Si) ≤ | 0.30
| Silicon (Si) ≤ | 0.70 | Manganese (Mn)
| Manganese (Mn) ≤ 1.60
Phosphorus (P) ≤ | 0.020 | Sulphur (S) ≤ | 0.020
Sulphur (S) ≤ | 0.010 | Other Alloying Elements | Moderate
| Other Alloying Elements | Add in Moderate Amounts | | Sulphur ≤ | 0.010
(Note: The above are typical values, the specific parameters are subject to the material certificate provided by our company).
Our Service and Commitment
Various specifications: We can provide different thickness, width and length of steel plates according to customers' requirements.3-150mm
Customised cutting: We provide accurate flame cutting, plasma cutting or laser cutting services to reduce your processing steps.
Professional technical support: Our technical team can provide you with professional advice on material selection, processing and welding.
Contact us today for a customised product solution and quotation!
